Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former

বেসিক ইনফরমেশন
Place of Origin: Botou Hebei China
পরিচিতিমুলক নাম: HC
সাক্ষ্যদান: ISO
Model Number: HC38-250-750
Minimum Order Quantity: 1set
মূল্য: 12000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
বিস্তারিত তথ্য
Type: Step tile width: 1000mm
Thickness: 0.3-0.6mm capacity: 4m/min
weight: 4T Warranty: 1 year
লক্ষণীয় করা:

roll forming equipment

,

cold roll forming machine


পণ্যের বর্ণনা

Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former



Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 1000mm

3. Rollers: 14 rows

4. Dimensions: 7.8*1.45*1.51m

5. Power: 4+4kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Glazed Tile Roll Forming Machine Main parameter

No.

   Main parameter of Glazed Tile Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

1000mm

3

Rollers

14 rows

4

Dimensions

7800*1450*1510m

5

Power

4+4kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

4m/min

8

Diameter of the roller

Φ70mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control



Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former 0Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former 1Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former 2Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former 3Produce roof tile forming machine/Glazed tile making machine/Steel sheet roll former 4

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-press form-cutting





Application



This type of glazed tile has advantage inclouding beautiful, classical appearance and grace taste. It can be widely used in village, hotel, exhibition, vocation vallage, family construction and outdoor decorate.





After-Sales Service

1. we can produce the special machine,send your drawing to us,we can design for you.



2. if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.



3. we provide a one year warranty and lifelong technical support, we can send our technicians to you to give you on-site training.



The training period would be for no more than one week with the customer paying for the visa, return ticket, food, accommodations and a daily wage of US100.



4. engineers available to service machinery overseas.



5. if you come to visit our factory,we can book the room for you, car pick up to send.



Thanks for visiting our products, if you have interest, pls leave your message, or you can contact us, speical design is avaliable!
